Home > Stainless Steel Angles
Ed Stainless is a leading supplier and manufacturer of top-quality stainless steel angles headquartered in Houston, Texas, USA. Known for providing accuracy-engineered products, Ed Stainless provides a complete assortment of stainless steel angles designed for industrial, commercial, and structural use. With an emphasis on quality, reliability, and customer satisfaction, the company offers materials that comply with both domestic and international requirements. Their stainless steel angles come in various grades and finishes, perfectly suited for construction, fabrication, and infrastructure applications. Ed Stainless continues to attend to clients from Houston and elsewhere, building a reputable name for itself in the stainless steel manufacturing sector.
Stainless steel angles from Ed Stainless are mainly produced with grades like 304, 304L, 316, and 316L. These grades have chromium (18–20%), nickel (8–14%), and traces of manganese, silicon, and carbon. The general mechanical properties comprise tensile strength of 515–620 MPa, yield strength of 205–290 MPa, and high elongation and hardness. These stainless steel angles provide superior corrosion resistance, high strength, and high durability in harsh conditions, and thus best suited for both indoor and outdoor structures, particularly in corrosive or harsh environments.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
At Ed Stainless, our stainless steel corners undergo rigorous testing to ensure quality and meet international standards. Certified for strength, durability and corrosion resistance, our products meet ISO and ASTM standards. Each batch is tested for chemical composition, mechanical properties and dimensional accuracy to ensure reliability and customer satisfaction.
Stainless steel angles are L-shaped structural components made from stainless steel. They provide strength and support for various applications, including construction, manufacturing, and architectural projects, offering durability and corrosion resistance.
Stainless steel equal angles have two legs of equal length, forming a 90-degree angle. They are used for structural support and reinforcement in construction, offering strength, durability, and corrosion resistance.
Stainless steel unequal angles have legs of different lengths, forming a 90-degree angle. They provide versatile support and reinforcement in construction and industrial applications, offering strength, durability, and corrosion resistance.
Stainless steel L angles are L-shaped structural components used for framing and support. They offer strength, durability, and corrosion resistance, making them suitable for construction, manufacturing, and architectural applications.
SS T-bar angles are stainless steel sections with a T-shaped profile, providing robust support and stability. They are used in structural applications and frameworks, offering high strength, durability, and corrosion resistance.
Stainless steel corner angles are L-shaped sections designed for joining or reinforcing corners in construction and fabrication. They provide strong, durable, and corrosion-resistant support for various structural and architectural applications.
Ed Stainless stainless steel angles are extensively applied in numerous industries because of their durability, corrosion resistance, and strength. They are used in support brackets, structural frames, shelves, racks, industrial platforms, and construction construction reinforcements. In marine and chemical industries, the angles are favored for being resistant to corrosive environments. The stainless steel angles are also applied in making machinery, architectural details, and transportation devices. Their adaptability and enduring durability make stainless steel angles a useful part of infrastructure, oil and gas, food processing, and industrial installations.
