Ed Stainless is a reliable and top-rated manufacturer and supplier of premium-quality stainless steel square pipes in Houston, Texas, USA. With years of experience and dedication to excellence, Ed Stainless has established a very good reputation for delivering precision-engineered stainless steel products that conform to national and international standards. Servicing numerous industries, the company provides a large inventory, quick delivery, and private labeling customized to the client. For structural purposes or for use as an aesthetic feature, Ed Stainless guarantees optimal quality, durability, and resistance to corrosion, and for this reason, they are the go-to option throughout Texas and the United States.
Ed Stainless produces stainless steel square pipes made from top-notch grades such as 304, 316, and 202, characterized by their superior corrosion resistance, hardness, and tensile strength. The pipes contain 18–20% chromium, 8–10.5% nickel, supplemented with molybdenum for improved resistance in grade 316. Some mechanical properties are high tensile strength (515–620 MPa), yield strength (205–275 MPa), and superior elongation and hardness. These features render Ed Stainless pipes perfect for demanding conditions where durability, cleanliness, and longevity are essential.
| Pipe Size | 12.75 X 12.75, 15 X 15, 20 X 20, 25 X 25, 30 X 30, 40 X 40, 50 X 50, 60 X 60, 75 X 75, 80 X 80, 90 X 90, 100 X100 |
| Grades | TP – 304/L/H, TP – 316/L/H/Ti, TP – 317L, TP – 321/H, TP – 347/H, 202, JT – 7, J4 – 1, TP – 409/L, TP – 410, TP – 430Ti, TP 439 |
| Standards | ASTM A249 – A269 – A312 – A358 – A409 – A554 – A778 – A789 – A790 |
| TOLERANCE on Length | Commercial Length: 6000mm +/- 30mm Fix Length: from 1200 mm up to 12000mm with a tolerance up to -0/+ 5mm |
| Finish | Polished Grit 120 – 600, Seamless, Welded, Brushed, Pickled, Solution Annealed and Pickled up to O.D. 219.1mm,Mirror Polished |
| STAINLESS STEEL PIPE GRADES | UNS | C | Mn | P | S | Si | Cr | Ni | Mo | Ti | Nb | N |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TP304 | S30400 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | ||||
| TP304L | S30403 | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | ||||
| TP316 | S3160 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |||
| TP316L | S31603 | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| Material | Heat | Temperure | Tensile Strength | Yield Strength | Elongation %, Min |
|---|---|---|---|---|---|
| Treatment | Min. | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
| º F(º C) | |||||
| TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP304L | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
| TP316 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP316L | Solution | 1900(1040) | 70(485) | 25(170) | 35 |
Contact us to get a quick quote for your requirement.
We manufacture and develop high-quality Stainless Steel Square Pipes and other industrial products, keeping in mind the requirements of clients from across the globe. Our Prime square pipes are accessible in different sizes, dimensions and specifications requested by the valuable customers. We offer customized and non- customized stainless steel pipes according to each project’s unique requirements assuring everyone has their perfect fit for various applications. Excellence in durability and dimension precision is a commitment, providing highest standards in all our products. Here at Ed Stainless, we understand customer expectations and serve with trust and efficacy with long-lasting products for all your piping requirements.
Yes, Stainless Steel Square Pipes can be used for potable water applications due to their corrosion resistance, durability, and non-reactive nature, making them safe and reliable for drinking water systems.
Yes, Stainless Steel Square Pipes are suitable for high-temperature applications, especially grades like 310 and 316, due to their excellent heat resistance, strength, and stability at elevated temperatures.
Stainless Steel Square Pipes are available in various configurations, including welded, seamless, and threaded. They come in different grades, such as 304, 316, and 310, to suit diverse applications.
Ed Stainless stainless steel square pipes are commonly applied in various industries because of their strength, resistance to corrosion, and visual appeal. Applications include building structures, support structures, handrails, architectural facades, and marine equipment. They are employed in the chemical processing industry, food and beverage facility, pharmaceutical manufacturing, and oil & gas pipelines in industrial environments. They can also be utilized for interior design, automotive, and transportation purposes due to their cleanliness and rust resistance. Ed Stainless provides every pipe to be of high quality, ensuring them to be used for commercial purposes as well as heavy-duty applications across Texas and other areas.
