Ed Stainless is a name that stands out among suppliers and manufacturers of stainless steel rectangle pipes in Houston, Texas, USA. As a powerful brand spread across the state, Ed Stainless stands out for its supply of high-quality, corrosion-free stainless steel solutions in accordance with international standards. Precision engineering combined with customer satisfaction has been the key to our establishment as a go-to brand among customers in construction, manufacturing, infrastructure, and industrial processes. Being a top manufacturer and supplier, we undertake timely delivery, tailor-made dimensions, and affordable prices, making Ed Stainless your one-stop shop for stainless steel rectangle pipes in Texas and more.
Texas-supplied stainless steel rectangle pipes by Ed Stainless consist mainly of iron, chromium (18–20%), nickel (8–10.5%), and traces of manganese, silicon, and carbon. These components provide superior corrosion resistance, hardness, and strength. The mechanical characteristics consist of a tensile strength of 515 MPa (minimum), yield strength of 205 MPa (minimum), and elongation of up to 40%, which makes them suitable for high-stress use. Ed Stainless ensures its products are up to ASTM A554/A312 standards in terms of quality and performance for all industrial applications.
| Size | 10 X 20, 12.75 X 25.4, 10 X 30, 15 X 30, 20 X 40, 20 x 50, 25 X 50, 20 x 60, 40 X 60, 40 X 80, 45 X 75, 50 X 100 |
|---|---|
| Grades | TP – 304, 304L, 316, 316L, 201 |
| Standards | A312 – A358 – A409 – A554 – A778 – A789 – A790 |
| Tolerance on Length | Commercial Length: 6000 milimeter +/- 30 milimeter Fix Length: from 1200 milimeter up to 12000 milimeter with a tolerance up to -0/+ 5mm |
| Finish | Polished Grit 120 – 600, Seamless, Welded, Brushed, Pickled, Solution Annealed and Pickled up to O.D. 219.1 milimeter,Mirror Polished |
| PIPE GRADES | UNS | C | Mn | P | S | Si | Cr | Ni | Mo | Ti | Nb | N |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TP304 | S30400 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | ||||
| TP304L | S30403 | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-13.0 | ||||
| TP316 | S3160 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |||
| TP316L | S31603 | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| Material | Heat | Temperure | Tensile Strength | Yield Strength | Elongation %, Min |
|---|---|---|---|---|---|
| Treatment | Min. | Ksi (MPa), Min. | Ksi (MPa), Min. | ||
| º F(º C) | |||||
| TP304 | Solution | 1900 (1040) | 75(515) | 30(205) | 35 |
| TP304L | Solution | 1900 (1040) | 70(485) | 25(170) | 35 |
| TP316 | Solution | 1900(1040) | 75(515) | 30(205) | 35 |
| TP316L | Solution | 1900(1040) | 70(485) | 25(170) | 35 |
Contact us to get a quick quote for your requirement.
The company also conducts various tests to ensure the pipes are of high standard before being shipped out. Some of the tests include Hardness Test, Chemical Analysis via Spectro Analysis, Positive Material Identification (PMI)-Testing, Flattening Test, Micro & Macro Test, Pitting Resistance Test, Flaring Test, and Intergranular Corrosion (IGC)-Test among others. In addition, the documentation is very complete for full traceability and observance of industrial standards.
Yes, stainless steel rectangle pipes can be welded using appropriate welding techniques such as TIG or MIG welding. Proper preparation and filler material are essential for strong, durable welds.
Stainless steel rectangle pipes are highly resistant to corrosion due to their chromium content. However, they may corrode in harsh environments with high chloride exposure or inadequate maintenance.
Yes, stainless steel rectangle pipes can be used for natural gas applications due to their strength, corrosion resistance, and ability to withstand high pressure, ensuring safe and durable performance.
Stainless steel rectangle pipes made from austenitic grades (like 304 and 316) are generally non-magnetic. However, some ferritic or martensitic grades may exhibit magnetic properties.
Ed Stainless rectangle pipes made of stainless steel are extensively utilized throughout Texas in numerous industries because they are strong, corrosion-resistant, and aesthetically finished. Typical uses involve structural support in building construction, architectural structures, transport components, marine equipment, food processing machinery, and chemical handling systems. Their strength to handle high pressure and severe conditions makes them suitable for indoor and outdoor applications. Ed Stainless provides these pipes in various grades and sizes to address both standard and bespoke project needs. For residential infrastructure or heavy industrial use, our rectangle pipes made of stainless steel provide unrivaled performance and durability.
